Product description:
With a 10.1-inch large adjustable LCD screen, the AD409 digital microscope comes with 4 megapixels HD sensor, 2 adjustable LED lights with stand, one HDMI cable and switch cable, one IR remote, and one UV filter (already assembled in the lens).
With a high-quality sensor, the digital microscope has max 4032x3024 (12M 4032*3024) photo resolution and can provide clear and high-quality images. Moreover, the magnification of AD409 can reach up to 300X and allows you to view the smallest solder joints on the large 10.1-inch display or on the external monitor connected with the microscope.
The AD409 supports PC connection, but only for Windows 7/8/10. The PC software with measurement is also supported. Last but not least, the AD409 digital microscope is able to be connected with mobile phones and tablets. By connecting with WIFI, the digital microscope can be used as a phone or iPad, permitting users to send images and photos from the microscope to a computer or another device.
(Note: Please download the software "My Measure App" at Google App Store.)
Features:
10.1-inch adjustable LCD screen;
4 MP image sensor, industrial lens;
PC/Mobile/Tablet connection supported; WIFI supported;
With measurement software, easy and convenient measuring
Up to 120FPS frame rate; real-time play via HDMI w/o recording;
UV filter, protect the lens from being dirty or damaged during soldering.
Adjustable stand, the microscope stand can move backward and forward, providing enough soldering working space.
Specifications:
|
Image sensor |
4 Mega Pixels HD Sensor |
|
Video output |
UHD2880x2160 24FPS; FHD1920x1080 60FPS/30FPS; HD1280x720 120FPS; |
|
Video format |
MP4; real-time play via HDMI w/o recording; |
|
Magnification |
Up to 300 times (HDMI monitor 27 inches) |
|
Photo resolution |
Max 4032x3024 (12M 4032*3024) |
|
Photo format |
JPG |
|
Focus range |
Minimum 5cm |
|
Frame rate |
Max 120FPS |
|
Video-output |
HDMI |
|
Storage |
Microscope-SD card, up to 32G |
|
Pc support |
Yes, for Windows 7/8/10, PC software with Measurement |
|
Mobile phone, tablet terminal support |
Support WiFi connection and measurement |
|
Power source |
5V DC |
|
Light source |
2 LED with the stand |
|
Screen size |
10.1 inch |
|
Stand size |
18cm*20cm*30cm |
|
Certification |
CE/FCC/ROHS/HDMI |
Package contents:
Microscope×1
Metal stand×1
UV filter (already assembled in the lens)×1
Instructions×1
IR remote×1
Switch cable×1
Power adapter×1
USB cable×1
HDMI cable ×1
Warranty:
1-year warranty.
