Item specifics:
Type: Mini PC
Graphics Card Type: Dedicated Card
Type: Mini Desktop
Processor Model: Xeon E-2176M/i7 8750H/i5 8300H/i9 8950HK
Processor Brand: Intel
Model Number: S200
Hard Drive Capacity: ≤ 40GB
Memory Capacity: ≤ 128MB
Use: Multimedia
Processor Main Frequency: Depends on CPU
Brand Name: EGLOBAL
Operating System: Windows 10, Linux, Ubuntu
Wireless: 2.4G/5G Wifi B/G/N/AC+bluetooth 4.0
Graphic Cards: Intel UHD Graphics supports 4K
Memory: 2*DDR4 1.2V laptop ram slots, max support 32GB
Storage Type: 1pcs*M.2 Nvme 22*80 SSD+1pcs*M.2 NGFF/Nvme 22*80 SSD+1pcs 2.5''SATA
Display Ports: HDMI+Mini DP
Product Size: 144*134*64MM
Ports: HDMI, Mini-DP, Gigabit Lan, 4*USB3.0, SPK/MIC, DC in
Color: Black
Core code: Coffee Lake 14nm
Feature: Palm Size
Case Material: Full Aluminum Alloy
Product Description:
Processor has 4 options:
1. 8th Gen 14nm CPU Coffee Lake Intel Core i7 8750H 6 cores 12 threads 2.2GHz up to 4.1GHz 9MB cache TDP 45W Intelreg UHD Graphics 630.
2. 8th Gen 14nm CPU Coffee Lake Intel Core i5 8300H 4 cores 8 threads 2.3GHz up to 4.0GHz 8MB cache TDP 45W Intelreg UHD Graphics 630.
3. 8th Gen 14nm CPU Coffee Lake Intel Xeon E-2176M 6 cores 12 threads 2.7GHz up to 4.4GHz 12MB cache TDP 45W Intelreg UHD Graphics P630.
4. 8th Gen 14nm CPU Coffee Lake Intel Core i9 8950HK 6 cores 12 threads 2.9GHz up to 4.8GHz 12MB cache TDP 45W Intelreg UHD Graphics 630.
How to select Configuration?
For example:
1. You click " No Ram No Storage" from Color and "CPU Core i5 8300H" from Bundle, we will ship the NUC with processor i5 8300H but no ram no storage included and No O/S to you.
2. You click " 8GB Ram 128GB SSD" from Color and "CPU Core i7 8750H" from Bundle, we will ship the NUC with processor i7 8750H 8GB Ram 128GB SSD and Windows preinstalled to you.
Barebone system no ram no storage, please use DDR4-2133/2400/2666 260pin laptop original brand Non-ECC SODIMM Ram and M.2 NVMe/NGFF/PCIE 3.0x4 SSD, don't support DDR3/L Ram installation. We do not make compensation for buyer's own ram and hard drive.
There is a film covered on surface to avoid scratches, please remove it to make surface smooth.
Free Operating System: Default installed our activated OEM windows 10 pro English for free, other languages can be selected among: Russian,Spanish,Portuguese,French,German,Arabic,Italian,Japanese,Turkish,Greek etc. Please inform us which language you want to install. Other systems we can install free are like Linux, XBMC(Kodi), Ubuntu, Openelec etc if you need. Seller is irresponsible and makes no compensation for OEM system.
Accessories as Ram, SSD, HDD, we use famous brand:samsung, micron, SanDisk, toshiba, hynix, crucial, liteon, kingfast, phison etc, What brand we use depends on our test and our stock.
|
ey Features |
CPU Platform |
|
|
|
Chipsets |
Intel 100 series PCH |
||
|
CPU install Method |
BGA1440 |
||
|
I/O Ports |
1*HDMI+1*Mini DP+1*Gigabit LAN port+4*USB 3.0+1*Type-C USB port+1*Audio Port | ||
|
CPU Leve 2 Cache |
Depend on CPU |
||
|
Chipsets |
intel PCH-LP |
||
|
Memory Support |
DDR4 1.2V 2133/2400/2666 260pins |
||
|
RAM Slot |
2 SO-DIMM Slots, support up to 32GB |
||
|
Storage |
1pcs*M.2 Nvme 22*80 SSD+1pcs*M.2 NGFF/Nvme 22*80 SSD+1pcs 2.5''HD |
||
| Wireless networking devices |
2.4G/5G Wifi B/G/N/AC+bluetooth |
||
|
Ethernet |
10/100/1000 BaseT LAN |
||
|
Network Card |
RTL8168E PCIE Gigabit ethernet NIC |
||
|
Power and Working Environment |
Input |
DC100-240V AC/50-60Hz |
|
|
Output |
DC 19V~3A-5A |
||
|
Operating Temperature |
0/70 Centigrade (32F~140F) |
||
|
Storage Temperature |
-20/+85 Centigrade |
||
|
Relative Humidity |
0%~90% (non-condensing) |
||
|
Energy-saving |
Support Energy-saving technology, Speedstep |
||
|
64 bit computing |
Support 64 bit computing |
||
|
Virtualization |
Support Virtualization technology |
||
|
Hyper-threading |
Support Hyper-Threading |
||
|
Consumption |
45W~60W |
||
|
Physical Properties |
Material |
Brushed Aluminum Alloy, a film covered on surface |
|
|
|
|||
|
Package Content |
1 Mini PC(Configuration according to the order); 1 power adapter,1*VESA mount,1*HDMI cable |
||
|
Warranty |
30 days free defective replacement and 3 years free repair |
- Unit Type: piece
- Package Weight: 2.5kg (5.51lb.)
- Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
