FIMIC Rotary Cutter Specifications & Capacities | ||
Model Number | FMCRCR06 | |
Hitch Type | CAT. 1, Quick-Hitch Ready | |
Cutting Width | 72" | |
Overall Width | 77" | |
Overall Length | 114" | |
Deck Height | 8-1/2" | |
Cutting Height | 1-1/2" ~ 11-1/2" | |
Cutting Capacity | 2" Diameter | |
Recommended Tractor PTO HP | 20-65 HP | |
PTO Speed | 540 RPM | |
Gearbox | 1:1.46 (smooth or 20 spline input) | |
Gearbox Oil Capacity & Lubricant | 4 Pints of EP 80-90W Oil | |
Deck Material Thickness | 10 Ga. (.134") | |
Side Skirt Material Thickness | 10 Ga. (.134") | |
Deck Construction | All Welded Deck | |
Skid Construction | Partial Length Welded On | |
Stump Jumper | Round Pan 10 Ga. x 27" with blade holder bar, 19-1/2 blade holder center to center | |
Blade x(2) | 6’ HD Blade with 3" Offset 1/2" x 3-1/2" x 27-1/2" | |
Blade Bolts | Keyed with Harden Flat Washers & Lock Nuts | |
Blade Tip Speed | 14,433 FPM | |
Driveline | #6 Series W or W/O Slip Clutch Connecting | |
Tailwheel | 4" x 8" x 15" Laminated Tire with Cast Iron Hub | |
Front/ Rear Guard (Optional) | Optional: Chain Guard | |
Weight/lbs | 854 |
