Spec:
- Voltage:14-75V( safe for 3-16S)
- Continuous Current : 200A
- Max Current :300A
- Supported sensors: ABI, HALL, AS5047,AS5048A
- EPRM:150000
Feature:
- Regenerative braking
- Sensored or sensorless operation + hybrid mode
- Configurable RPM-, current-, voltage- and power limits
- Input source: PPM, Analog, NRF Nyko Kama Nunchuck
- Communication ports: USB, CAN, UART
- Throttle curve and ramping for all input sources
- Seamless 4-quadrant operation
- Motor revolution, amp hour, watt hour counting
- Real time data analysis and read out via communication ports
- Adjustable protection against:
- Low input voltage
- High input voltage
- High motor current
- High input current
- High regenerative braking current (separate limits for the motor and the input)
- High RPM (separate limits for each direction)
- Digital VCC and analog VCC are produced by different voltage regulators respectively to make the system AD conversion more accurate
- Motor wire: 8AWG
- Power cable: 10AWG
-
Wiring Diagram With Aluminum Case:
