DESCRIPTION
Take your deep cycle battery experience to the next level by investing into Renogy's LFP Battery, combining superior lithium-iron phosphate technology to provide a better solution to solar energy storage. Weighing at just a bit over 14.8 lbs, Renogy's LFP battery surpasses expectation by being lighter, compact, and more powerful than its lead-acid battery counterparts of 50Ah. Designed to replace conventional solar battery storage units such as sealed Sealed, AGM, or Gel batteries, utilize your LFP battery in power-sport applications, off-grid applications, solar energy storage, and more! Take a step into the right direction by pairing your solar system with one of the safest and highest-cycle battery chemistry yet.
The Renogy Adventurer Li and Rover charge controller are fully compatible with this battery. If you have any questions regarding this product, please call us at 1 (909)287-7111 or email support@renogy.com.
Note:
- Please be aware that if the batteries' Battery Management System (BMS) is activated and the battery voltage shows 0V, you must use a compatible Li charger to reactivate our Li batteries.
- Make sure to tightly screw the battery terminals in, having loose battery terminals will cause the terminals to build up heat resulting in damage to the battery.
- DO NOT string this battery in series. It is made ONLY for parallel connections using identical batteries.
KEY FEATURES
- Lightweight
- BMS protection
- Low Self-discharge
- Triplex Sealed Construction
- Patent Designed Construction
MINIMUM 12V LITHIUM BATTERY BANK SIZING
The following are the minimum battery quantities to operate Renogy power inverters. This is ONLY for 12V applications.
| BATTERY BANK QTY/ INVERTER SIZE | 50AH | 100AH | 170AH |
|---|---|---|---|
| 700W | 1 | 1 | 1 |
| 1000W | 2 | 1 | 1 |
| 2000W | 4 | 2 | 1 |
| 3000W | 6 | 3 | 2 |
PACKAGE INCLUDES
|
Renogy Lithium-Iron Phosphate Battery 12 Volt 50Ah
1 x |
| ELECTRIC CHARACTERISTICS | |
|---|---|
| Nominal Voltage: 12.8V | Energy Density: 114.4Wh/L |
| Rated Capacity (0.2C): 50Ah | Internal Resistance: ≤50mΩ |
| Minimal Rated Capacity (0.2C): 47.5Ah | Cycle Life (0.2C, 20±5°C): 80% DOD 2000 cycles |
| Energy: 640Wh | Specific Energy: 95.5Wh/kg |
| CHARGING PARAMETERS | DISCHARGE PARAMETERS |
|---|---|
| Charge Voltage: 14.4 ± 0.2V | Maximum Continuous Discharge Current: 50A |
| Maximum Charge Current: 50A | Discharge Cut-off Voltage: ≥10V |
| Charge Cut-off Voltage: 14.6V |
| TEMPERATURE PARAMETERS OPERATION TEMPERATURE RANGE | TEMPERATURE PARAMETERS STORAGE TEMPERATURE RANGE |
|---|---|
| Charge:32~113℉ / 0～45℃ | Less Than 1 Year:32~77℉ / 0~25℃ |
| Discharge:-4~140℉ / -20～60℃ | Less Than 3 Months:23~95℉ / -5~35℃ |
| Recommended:73.4 ± 9℉ / 23 ± 5℃ |
| MECHANICAL PROPERTIES | |
|---|---|
| Length: 197mm / 7.8 inch | Weight: 6.7 kg / 14.7 lbs. |
| Width: 166mm / 6.5 inch | Housing Material: ABS+PC |
| Height: 171mm / 6.7 inch | Terminal Model: M8x1.25x12mm |
| Cell Model: IFR26650-3.4Ah | Assembly Method: 4S15P |
WARRANTY INFORMATION
| Accessories | 5-year prorated warranty |
