Type: Helicopter;Features: Remote Control;Aerial Photography: No;Age Range: 8-11 Years,> 14 years old,> 8 years old,12-15 Years,Grownups;Dimensions: As Description;State of Assembly: Ready-to-Go;Package Includes: USB Cable,Charger,Original Box,Operating Instructions,Batteries,Remote Controller;Material: Plastic,Metal;Action Time: As Description;Model Number: SPC 95GF;Charging Voltage: As Description;Control Channels: 4 Channels;Controller Mode: MODE1,MODE2;Warranty: As Description;Plugs Type: As Description;Warning: NO;Remote Distance: As Description;Controller Battery: As Description;Charging Time: As Description;Power Source: Electric;Remote Control: Yes;Brand Name: EACHINE;Motor: Brushless Motor;Package Includes: As Description;Features: Model;
Return:
Specification:
Brand name: SPC Maker
Product model: SPC 95GF
Wheelbase: 95mm
Size: 76mm*87mm*50mm
Weight: 72g (without battery)
Flight weight: 105g (include battery)
Motor: SPC Maker S1104 7500KV brushless motor
ESC: Mini 4 in 1 BLheli_s ESC (2-4S LiPo)
Propeller: 50mm 4-blades propeller
Receiver: Frsky/DSM X/Flysky/Futaba(optional)
Camera: RunCam Micro Swift 1/3 "600TVL FPV camera 2.1mm lens CCD camera
VTX: 5.8g 25MW-200MW 48CH Video transmitter
Flight controller: OSDOminibus F3 flight controller integrated with OSD module
OSD: Betaflight OSD
Firmware of flight controller: Betaflight_3.1.0_OMNIBUS
Flight time: 4 minutes
Rear LED Ready( LED_Strip function)
Buzzer Ready
Battery: 11.1V 350mAh 30C lipo battery
Ominibus F3 flight controller integrated with OSD module:
-Powered by MPU6000 sensor for quick response to acceleration, integrated with 5V/1A BEC and OSD module
(This is 6DOF version, no barometer and compass).
-Designed for small size FPV quads with a frame smaller than 280mm, especially ideal for quadcopters smaller
than 130mm to exhibits its advantages in small Sizes and multiple functions.
-It provides all the functions of F3 6DOF version, but weighs only 8 grams. The size is only 27*27mm. Mounting
hole size is 20mm (2.5mm hole).
-Designed for quadcopter with LC filter. It supports CF and BF firmware (Omnibus F3)
-STM32F3CCT6 microprocessor, 256K memory, MPU6000 sensor, SPI port, faster processing speed.
-Constant current: 10A*4 (maximum current: 15A*4, 5s)
-Supports 2-4S LiPo input.
-Built-in 5V 1A BEC.
-Supports popular receivers such as SBus, PPM, DSM X.
-Buzzer, programmable LED, voltage monitoring, HLHeli ESC.
4 in 1 BLheli_s ESC:
Input voltage: 2-4S LiPo and 2-4S HV LiPo
BEC Output: Not available
Constant current of a single ESC unit: 10A
Maximum current: 15A 5 second.
Sizes: 27*27mm (main board)
31*31.5mm (including soldering pads and extruded part)
Weight: 6.3g
Firmware: BLHeli_s
Supports D-Shot, Oneshot, rotation directions.
Processor: SILABS EFM8BB21F16G
MOS FET: TPN2R703NL
Driver: new generation 3 in I MOS
Camera parameters:
Frequency : 5362-5945MH
Channel: 48
Modulation type: FM
Select channel: switch
Channel display: CH1-CH8 channel display with 8 LEDs, and A-F frequency group display with 6 LEDs
Transmit power: 13±1dBm
Frequency control: PLL
All harmonic: Max-50 dBm
Frequency stability: ±100KHz(Typ.)
Frequency precision: ±200KHz (Typ.)
Channel disk failure: 1dB
Antenna port: 50 Ω
Input format: NTSC/PAL
SENSOR: PAL: 720×540/NESC: 640×480 1/4 "
LENS ANGEL: H: 120 °/ V: 100 °
Base interface: P1, 27*2
Energy consumption: 200-215MA@5V DCIN
Supply voltage: 2.9-5, 5V
Operating temperature:-10℃~+ 60℃
Profile dimension: 14, 5 mm×12, 2 mm+14, 5 mm×12 mm
Compatible:
1.For DSM 2 Receiver Support Spectrum/JR(DSM 2 protocol) DEVO10/DEVO 7E (with deviation firmware).
2.For Frsky Receiver Support FRSKY taranis X9D/X9D PLUS (D16 mode), and XJT (D16 Mode), DJT DFT DHT Transmitter.
3.For Flysky Receiver Support FS-I6, FS-I6X, FS-I6S, FS-TM8, FS-TM10, FS-I10 and other second-generation AFHDS 2A
protocol remote control
4.For Futaba Receiver Support TM7,TM8, TM10, TM14 T6EX-2.4G, 7C-2.4G, T8FG, T10CG , T12FG.T14SG.
Receiver Setup and Binding Methods
Package include:
1 x SPC Maker 95GF Frame
1 x Ominibus F3 flight controller integrated with OSD module
1 x Frsky/DSM X/Flysky/futaba(optional receiver)
4 x SPC Maker 1104 7500KV brushless motor
1 x Mini 4 in 1 BLheli_s ESC (2-4S LiPo)
4 x 50mm 5-blades propeller CW
4 x 50mm 5-blades propeller CCW
1 x RunCam Micro Swift 1/3 "600TVL FPV camera 2.m lens CCD camera
1 x 5.8G 25mW-200mW 48CH VTX
2 x 11.1V 350mAh 30C lipo battery (comes without charger)
1 x WS2812 LED Board
4 x 3*100mm nylon
1 x 12mm*150mm magic
2 x 15mm*50mm back to back with rubber magic belt
1 x XT60 female plug to XT30 male plug converter
Brand name: SPC Maker
Product model: SPC 95GF
Wheelbase: 95mm
Size: 76mm*87mm*50mm
Weight: 72g (without battery)
Flight weight: 105g (include battery)
Motor: SPC Maker S1104 7500KV brushless motor
ESC: Mini 4 in 1 BLheli_s ESC (2-4S LiPo)
Propeller: 50mm 4-blades propeller
Receiver: Frsky/DSM X/Flysky/Futaba(optional)
Camera: RunCam Micro Swift 1/3 "600TVL FPV camera 2.1mm lens CCD camera
VTX: 5.8g 25MW-200MW 48CH Video transmitter
Flight controller: OSDOminibus F3 flight controller integrated with OSD module
OSD: Betaflight OSD
Firmware of flight controller: Betaflight_3.1.0_OMNIBUS
Flight time: 4 minutes
Rear LED Ready( LED_Strip function)
Buzzer Ready
Battery: 11.1V 350mAh 30C lipo battery
Ominibus F3 flight controller integrated with OSD module:
-Powered by MPU6000 sensor for quick response to acceleration, integrated with 5V/1A BEC and OSD module
(This is 6DOF version, no barometer and compass).
-Designed for small size FPV quads with a frame smaller than 280mm, especially ideal for quadcopters smaller
than 130mm to exhibits its advantages in small Sizes and multiple functions.
-It provides all the functions of F3 6DOF version, but weighs only 8 grams. The size is only 27*27mm. Mounting
hole size is 20mm (2.5mm hole).
-Designed for quadcopter with LC filter. It supports CF and BF firmware (Omnibus F3)
-STM32F3CCT6 microprocessor, 256K memory, MPU6000 sensor, SPI port, faster processing speed.
-Constant current: 10A*4 (maximum current: 15A*4, 5s)
-Supports 2-4S LiPo input.
-Built-in 5V 1A BEC.
-Supports popular receivers such as SBus, PPM, DSM X.
-Buzzer, programmable LED, voltage monitoring, HLHeli ESC.
4 in 1 BLheli_s ESC:
Input voltage: 2-4S LiPo and 2-4S HV LiPo
BEC Output: Not available
Constant current of a single ESC unit: 10A
Maximum current: 15A 5 second.
Sizes: 27*27mm (main board)
31*31.5mm (including soldering pads and extruded part)
Weight: 6.3g
Firmware: BLHeli_s
Supports D-Shot, Oneshot, rotation directions.
Processor: SILABS EFM8BB21F16G
MOS FET: TPN2R703NL
Driver: new generation 3 in I MOS
Camera parameters:
Frequency : 5362-5945MH
Channel: 48
Modulation type: FM
Select channel: switch
Channel display: CH1-CH8 channel display with 8 LEDs, and A-F frequency group display with 6 LEDs
Transmit power: 13±1dBm
Frequency control: PLL
All harmonic: Max-50 dBm
Frequency stability: ±100KHz(Typ.)
Frequency precision: ±200KHz (Typ.)
Channel disk failure: 1dB
Antenna port: 50 Ω
Input format: NTSC/PAL
SENSOR: PAL: 720×540/NESC: 640×480 1/4 "
LENS ANGEL: H: 120 °/ V: 100 °
Base interface: P1, 27*2
Energy consumption: 200-215MA@5V DCIN
Supply voltage: 2.9-5, 5V
Operating temperature:-10℃~+ 60℃
Profile dimension: 14, 5 mm×12, 2 mm+14, 5 mm×12 mm
Compatible:
1.For DSM 2 Receiver Support Spectrum/JR(DSM 2 protocol) DEVO10/DEVO 7E (with deviation firmware).
2.For Frsky Receiver Support FRSKY taranis X9D/X9D PLUS (D16 mode), and XJT (D16 Mode), DJT DFT DHT Transmitter.
3.For Flysky Receiver Support FS-I6, FS-I6X, FS-I6S, FS-TM8, FS-TM10, FS-I10 and other second-generation AFHDS 2A
protocol remote control
4.For Futaba Receiver Support TM7,TM8, TM10, TM14 T6EX-2.4G, 7C-2.4G, T8FG, T10CG , T12FG.T14SG.
Receiver Setup and Binding Methods
Package include:
1 x SPC Maker 95GF Frame
1 x Ominibus F3 flight controller integrated with OSD module
1 x Frsky/DSM X/Flysky/futaba(optional receiver)
4 x SPC Maker 1104 7500KV brushless motor
1 x Mini 4 in 1 BLheli_s ESC (2-4S LiPo)
4 x 50mm 5-blades propeller CW
4 x 50mm 5-blades propeller CCW
1 x RunCam Micro Swift 1/3 "600TVL FPV camera 2.m lens CCD camera
1 x 5.8G 25mW-200mW 48CH VTX
2 x 11.1V 350mAh 30C lipo battery (comes without charger)
1 x WS2812 LED Board
4 x 3*100mm nylon
1 x 12mm*150mm magic
2 x 15mm*50mm back to back with rubber magic belt
1 x XT60 female plug to XT30 male plug converter
